Model Description
-
HBL Model Name:
HSU-36CassetteType:(Fix)
-
IDU Code:
AB105S1SR1FA
-
ODU Code:
1U105S1LN1SB
-
Panel Code:
PB-950QB
Capacity
-
Cooling (BTU/h):
36000
-
Heating (BTU/h):
Not Applicable
Power Input
-
Cooling (W):
3300
-
Heating (W):
Not Applicable
Energy Class
-
EER:
3.18
Running Current
-
Cooling (A):
5.32
-
Heating (A):
Not Applicable
Power Supply
-
(Ph, V, Hz):
3/380~415/50
Air Flow
-
H/M/L/So (m3/h):
2080/1780/1580/1400
Moisture Removal Capacity
-
(10-3m3/h):
2L/H
Refrigerant Type
-
Refrigerant Type:
R32
Refrigerant Pipe
-
Liquid Side Diameter (mm):
9.52
-
Gas Side Diameter (mm):
15.88
Indoor
-
Net Dimension (mm) W/D/H:
840/840/246
-
Package Dimension (mm) W/D/H:
978/978/312
-
Net Weight (kg):
25
-
Gross Weight (kg):
30.5
-
Sound power Level [dB(A)] Hi/Mid/Lo:
53/50/47/43
Outdoor
-
Net Dimension (mm) W/D/H:
950/370/965
-
Package Dimension (mm) W/D/H:
1050/485/1095
-
Net Weight (kg):
74
-
Gross Weight (kg):
85
-
Sound Power Level [dB(A)] Hi/Mid/Lo/So:
59
-
Compressor Type:
Rotary
Panel
-
Model:
PB-950QB
-
External Dimensions (W/D/H) mm:
950/950/50
-
Packing Dimensions (W/D/H) mm:
1000/1000/110
-
Net Weight (KG):
5.5
-
Gross Weight (KG):
8.5
Special Features
-
DC Fan Motor:
Yes
-
Large Heat Exchanger Design:
Yes
-
Multiple Air Speed for Ultimate Comfort:
Yes
-
Hidden LED Display:
Yes
-
Automatic Airflow Control:
Yes
-
Installation Friendly:
Yes
-
Convenient Filters:
Yes
-
Energy Saving:
Yes
-
Super Big Inlet Grille:
Yes
-
Brand New Designed Fan:
Yes
-
Individual Flap Control:
Yes
-
High Ceiling Mode:
Yes
-
Round Way Air Supply:
Yes
-
High Lift-up Drain Pump:
Yes
